OLED lighting module SL
Specifications
| OLED panel | 3000 K standard | 3000 K high color rendering | 4000 K high color rendering | |||
|---|---|---|---|---|---|---|
| Product number | LE-01L | LE-01H |
LE-02L | LE-02H |
LE-03L | LE-03H |
| Total luminous flux (100% dimming) | 69 lm | 114 lm | 57 lm | 94 lm | 50 lm | 82 lm |
| Power consumption (100% dimming) | 2.5 W | 3.6 W | 2.5 W | 3.6 W | 2.5 W | 3.6 W |
| Input voltage | DC24V | |||||
| External dimensions | 94 mm x 94 mm x 5 mm (Lighting Module SL only) | |||||
| Size of light-emitting part | 80 mm x 80 mm | |||||
| Weight | 40 g (Lighting Module SL only) | |||||
| Dimming method | PWM dimming* | |||||
| Dimming range | 5% to 100% | |||||
*Can also be controlled with DALI and DMX.
- The product specification and design are typical values and are not guaranteed.
Download the catalog for OLED lighting module SL
Download the operaion manual for OLED lighting module SL
Example: Bedside reading lamp
With the reading lamp, now being built directly into the headboard additional space can be freed up, for example, new shelf area is made possible because of KANEKA OLED's thin and light weight feature.
